Single warp fiberglass fabricSpecifications
1.High Tensile Strength and Quick Wet out
2.Perfect designable character
3.Stability
4.Stiffnes
Single warp fiberglass fabric is made of fiberglass direct roving parallel aligned in 0°directions, then stitched by polyester yarn. Also can select to add chopped strand layer or non-woven fabric layer stitched together. It is compatible with Polyester, Vinyl and Epoxy resin and widely used in wind energy, boat building, FRP pipes and tanks, pultrusion section industry etc, suitable for pultrusion, hand lay up, filament winding, vacuum infusion processes.stems.
Technical Specification:
Code |
Weight (g/m2) | 0°Warp (g/m2) | 90°Weft (g/m2) |
Chop strands (g/m2) |
Polyester tissue (g/m2) |
Layer |
EL336 | 336 | 336 | - | - | - | 1 |
EF400 | 400 | 400 | - | - | - | 1 |
EF420 | 420 | 400 | - | - | - | 1 |
EF560 | 560 | 560 | - | - | - | 1 |
EF600 | 600 | 420 | 180 | - | - | 2 |
EFT625 | 625 | 400 | - | 225 | - | 2 |
EF625/N45 | 670 | 400 | - | 225 | 45 | 3 |
EF672 | 672 | 672 | - | - | - | 1 |
EF800 | 800 | 672 | 128 | - | - | 2 |
EFT900 | 600 | 600 | - | 300 | - | 2 |
Package & Storage:
The fabrics should be stored away from heat and moisture, and in their original packaging. The best conditions are : temperatures between 15 and 35 , humidity between 35 and 65%. If the product is not stored under these specifications , it is advisable to condition it in the workshop for at least 24 hours before use, to prevent condensation. The pallets can be stored in 2 levels(1/1).Tianma recommends that the material be used according to FIFO(first in, first our)method. It is recommended the use of a spacer plae(10mm) between the pallets.
